HORIZONTAL FLOW WRAP PACKING MACHINE SZ-3000

HORIZONTAL FLOW WRAP PACKING MACHINE SZ-3000

MODEL:
SZ-3000

Application:
It is suitable for packing all kinds of irregular articles, sticky articles and solid objects.
1. Food: noodles, egg rolls, sausages, squid, bread, moon cakes, preserved fruit, soft candy, etc.
2. chemical categories: soap, tape, etc.
3. electrical switch: plug board, switch, etc.
4. Other categories: wind oil essence, pocket notepad, boxed pen, medicine, etc.


Brochure

Categories ,

Specification

Model SZ-3000 (Single Jaw) SZ-100 (Double Jaws)
Package Length 120~500 mm 60~200 mm
Package Width 35~160 mm 35~80 mm
Package Height 5~60 mm 5~35 mm
Packing Speed 30~120 bags/min. 30~250 bags/min.
Film Size 90~400 mm
Packaging Film Type PP. PE, PVC, PS, EVA, PET, PVDC+PVC, OPP+CPP
Type of Power Supply 220V
General Power 3.1 Kw 3.8 Kw
Weight of Machine 350Kg
Dimension 4100 x 770 x 1100 mm

Features:

  • The whole machine is controlled by three servos.
  • Seven-inch touch screen display, easy operation and clear working status.
  • Variety of product parameters and formulas can be stored, which can be downloaded and used without repeated settings.
  • Automatic adjustment of bag length without manual setting.
  • Higher precision and accurate sealing and cutting position.
  • Stop position and print position can be set arbitrarily.
  • The packaging range is expanded to adapt to a variety of product specifications.
  • Reduce the labor intensity of the operator, effectively improve production efficiency.
